Automated Fish Vaccination Machine · CE Marked
Thirty-eight years
in fish health
A new fish vaccination machine
An automated intraperitoneal fish vaccination machine built for fish from 10 to 200 g, designed by a team that has worked in fish health for thirty-eight years and running in daily commercial production since 2025.
10–200 g
Fish weight range
0.01–0.25 ml
Dose range
15,000/hour
Recommended throughput
8
Sites trialled and in operation
38 yearsin fish health
The working life behind this brand goes back to 1988, to what was then the second hatchery in Türkiye. Throughout that period the company has supplied vaccines and immunostimulant feed additives, built vaccination programmes by species and pathogen, and carried those programmes out in the field. The fish vaccination machine, in development since 2022, comes out of the same body of experience and has been in daily commercial production since 2025.
Engineering
Design priority: uptime and on-site servicing
The design of the fish vaccination machine is built on simplicity. Dosing is mechanical: the setting is fixed and needs no calibration, so the dose delivered on the last day of the season is the dose delivered on the first. The heads work independently of one another, each with its own vaccine feed, and can also be run on different formulations. Routine servicing is carried out on site by the facility's own crew; the machine is designed for it.
Mechanical dosing
The same volume, every injection
Positive displacement: the piston stroke is mechanically limited, so the delivered volume does not depend on vaccine viscosity, temperature or supply pressure. The stroke alone sets the volume, and no calibration routine is required.
Configuration
From a single head to sixteen
Configuration starts from a single head and is set to the facility's need. The standard AEV-8 carries 8 heads in a 4×2 layout, chosen after different head counts were tried in the field; the model number is the head count, AEV-4 to AEV-16, and intermediate and odd head counts are built to order.
Deployment
On land, on the water, easily moved
The machine runs in land-based hatcheries and on floating platforms at sea cage sites. Because dosing is mechanical rather than sensed, the delivered volume stays constant under moderate wave motion, and vibration is damped on the platform. The load-bearing structure is 316 stainless steel, the profiles and fittings anodised aluminium, selected for contact with seawater and salt. It has been trialled on a floating platform at a sea cage site on the Aegean, and stays compact enough to be moved between rooms or sites as the season requires.
Continuity
Scales cleared automatically, every injection
After every injection the needle is cleared automatically, while the machine is running and without anyone touching it, so the needle stays clear of scale and tissue. The same action limits tissue passing from one fish to the next and reduces the risk of cross-contamination; the needle enters every fish clean.
Fish welfare
Same point, same depth, every fish
In hand injection, depth and angle depend on the operator and vary over a long shift. Here the fish is held in a fixed position and the holder height is set to its size, so it stays steady as the needle goes in. The needle enters at the same point and the same depth every time, the injection site is protected, and the dose is placed where the protocol requires it. The needle goes in and comes out quickly, so the point of entry closes behind it.
Operator safety
The operator's hands stay clear of the needle
The fish is loaded outside the injection zone, and the operator's hands stay clear of the needle while the machine is running. Needle-stick injury and accidental self-injection are the two incidents every vaccination crew guards against; a design that keeps the operator's hand away from the needle removes the contact they arise from.
Verification
Every head counts itself
Each head keeps its own tally and one summary panel shows them together. Every vaccinated fish is recorded, so the operations manager and the fish health officer can check the figure against the stocking figures at any time. Counting head by head shows how the run is going while the work is in progress, not at the end of the season.
Monitoring
It brings its own network
Each machine broadcasts its own local Wi-Fi hotspot and connects to an Android app over the hotspot or over Bluetooth, so the counts can be read at the machine or from a phone within the hotspot's range; on request, the remote connection and monitoring system makes them readable from further away as well. There is no corporate network to join, no cabling to run and no IT approval to wait for, and the machine works the same way whether or not the facility has an internet connection. In the standard configuration counts and operating data stay inside the facility as the facility's own records and are not sent to an external server or a cloud account.
Installation
Air and power. Nothing else
No dedicated water supply, network connection or purpose-built room. Compressed air and electricity are the only services the machine needs from the facility, which is what allows it to be commissioned quickly and moved later without further site works.
Performance in production
Fish vaccination machine values, measured in production
These figures come from a machine in daily commercial use, not from a bench rating. The machine has been running since 2025 at Noordzee Su Ürünleri A.Ş. in Türkiye, and has been trialled on sea bass and on rainbow trout at further sites on the Aegean coast, on the Black Sea coast and inland.
15 million
Fish vaccinated to date
The approximate total the machine has delivered so far, in field trials and in daily commercial production together.
120,000
Fish per shift
Approximate output over an eight-hour shift at the recommended throughput, in the standard AEV-8 configuration. At that pace each head vaccinates a fish approximately every two seconds; the engineering rating of the AEV-8 allows up to approximately 25,000 fish per hour. The machine is run by the facility's own shift staff, with no need to bring in a professional vaccination crew, and reaching the same output by hand injection takes a crew close to three times the size.
10,000
Doses per litre
Approximate vaccine consumption at a 0.1 ml setting, held steady by the mechanical stroke limit.
Reference site
Running in daily production
The machine has been in daily commercial production at the Noordzee Su Ürünleri A.Ş. facility since 2025.
Field trials
Sea bass on the Aegean, trout on the Black Sea and inland
On the Aegean the machine has been trialled on sea bass at four sites: the hatcheries of Kılıç Deniz Ürünleri Üretimi İhracat İthalat ve Ticaret A.Ş. and Abalıoğlu Balık ve Gıda Ürünleri A.Ş. in Bodrum, the Akvatek Su Ürünleri A.Ş. hatchery in Çeşme, and a floating platform at a sea cage site. Trials on rainbow trout at Kuzuoğlu Su Ürünleri Sanayi ve Ticaret A.Ş. and one further producer on the Black Sea coast, and at an inland site in Elazığ, were also concluded successfully.
Weight range
Vaccination from 10 g upward
The lower bound is the point at which dip vaccination stops and injection begins, so fish can be vaccinated earlier, while they are still in a land-based facility. The upper bound is 200 g. Suitable for sea bass, sea bream, trout, salmon and other farmed fish species.
Technical specification
Every technical value of the fish vaccination machine
The technical values are published below. Power and compressed air consumption, together with machine dimensions and weight, change with the number of heads and are therefore stated per configuration in the quotation.
AEV-4
- Heads
- 4, in a 2×2 layout
- Recommended throughput
- Approx. 7,500 fish/hour
AEV-8
Standard
- Heads
- 8, in a 4×2 layout
- Recommended throughput
- Approx. 15,000 fish/hour
AEV-12
- Heads
- 12, in a 6×2 layout
- Recommended throughput
- Approx. 22,500 fish/hour
AEV-16
- Heads
- 16, in an 8×2 layout
- Recommended throughput
- Approx. 30,000 fish/hour
Intermediate and odd head counts are built to order; the configuration is built to the facility's need, starting from a single head.
Dosing and species
Product
Automated intraperitoneal (IP) fish vaccination machine
Fish weight range
10–200 g
Species
Sea bass, sea bream, trout, salmon and other farmed fish species
Species trialled in the field
Sea bass and rainbow trout, across eight sites in Türkiye including the reference site
Dose range
0.01–0.25 ml
Dose setting
Set to the customer's protocol prior to order; can be changed on request
Dosing mechanism
Positive displacement. The piston stroke is mechanically limited, so delivered volume is independent of vaccine viscosity, temperature and supply pressure.
Vaccine consumption
Approx. 10,000 doses per litre at a 0.1 ml setting
Vaccine formulations
Each head has its own vaccine feed, so the heads can be run on different formulations: on the AEV-8, each of the eight heads can carry a different vaccine. Each head carries its own stroke setting, so a change of formulation does not call for recalibration.
Head count
Set to the facility's need, starting from a single head. Standard models have 4, 8, 12 and 16 heads; intermediate and odd head counts are built to order.
Capacity
Model range
AEV-4 · AEV-8 · AEV-12 · AEV-16. The model number is the head count.
Standard configuration
AEV-8 — 8 heads in a 4×2 layout
Recommended throughput (AEV-8)
Approx. 15,000 fish/hour · approx. 120,000 fish per 8-hour shift
Maximum throughput (AEV-8)
Approx. 25,000 fish/hour · approx. 200,000 fish per 8-hour shift (engineering rating)
Operators required
1 operator per 2 heads, for placing the fish only — 4 operators on the AEV-8
Operation
Loading
Every operation on the machine is automated; only placing the fish is done by hand
Injection consistency
The machine vaccinates every fish at the same point and to the same depth
Operator safety
The operator's hands stay clear of the needle while the machine is running
Scale removal
Scales are cleared from the needle automatically after every injection
Counting
Each head counts independently; one combined summary panel shows the total. Every vaccinated fish is counted, and the records are held permanently in a separate, protected layer.
Monitoring
Connects to a companion Android application over a local Wi-Fi hotspot broadcast by each machine and over Bluetooth. In the standard configuration monitoring stays within the facility; no connection to a corporate network or external server is needed. Remote connection and monitoring can be configured on request.
Height adjustment
The holder height is set to the size of the fish
Construction and installation
Installation requirement
Compressed air and electricity only
Body material
Load-bearing structure in 316 stainless steel; profiles and fittings in anodised aluminium. The parts that make up the body are selected for contact with seawater and salt, and the outer body can be washed down with pressurised water.
Deployment
Land-based hatcheries and floating platforms at sea cage sites; the delivered volume stays constant under moderate wave motion and vibration is damped on the platform
Set-up time
Set up and ready to vaccinate in under an hour, once the machine has been moved
Power consumption
Varies with head count; stated in the quotation
Compressed air consumption
Varies with head count; stated in the quotation
Dimensions and weight
Varies with head count; stated in the quotation
Commercial
Certification
CE marked. Certificates for the components used in the machine are provided with the quotation for the configuration selected.
Support
On-site installation, operator training and remote support through the season
Delivery
Delivery terms are stated using Incoterms. Transport and delivery conditions are given in the quotation.
EU Declaration of Conformity
Issued for the machine supplied
Capacity and throughput figures are approximate. Output on site varies with species, fish weight and condition, water temperature, facility layout and the experience of the operating crew. This does not apply to dose range, weight range and head count: these are design specifications, set to the customer's protocol before the order.
Service and spare parts
Installation, training and season-long support after delivery
What stands behind a fish vaccination machine matters as much as the machine itself. The path from installation to the end of the season is set out below.
01 / Installation
Installed and started up on site
The machine is installed at the customer's own facility, connected and set up. Installation is complete once the machine is running under production conditions.
02 / Training
Operators trained on site
Training in loading, monitoring and routine maintenance is delivered on the machine supplied, with the facility's own crew and at the facility itself.
03 / Season support
Reachable through the season
Remote support runs through the vaccination season. Questions raised during the season are answered by the team that knows the machine.
Spare parts list — prepared for each machine and provided with the quotation.
Questions and answers
Frequently asked questions about the fish vaccination machine
What is Aegean Vaccine?
Aegean Vaccine is the brand of an automated fish vaccination machine built in Urla, İzmir. The brand belongs to İzmir Paketleme Lojistik İnşaat Sanayi ve Ticaret Ltd. Şti. The machine delivers intraperitoneal vaccine to farmed fish from 10 to 200 g.
Which species is the fish vaccination machine used on?
Sea bass, sea bream, trout, salmon and other farmed fish species. In the field it has been trialled on sea bass and rainbow trout.
How many fish does the machine vaccinate per hour?
In the standard AEV-8 configuration the recommended throughput is approximately 15,000 fish per hour, about 120,000 fish in an eight-hour shift. The figures are approximate and vary with species, fish weight, water temperature and the experience of the crew.
How many heads can the machine be configured with?
Configuration starts from a single head and is set to the facility's need. The standard models have 4, 8, 12 and 16 heads; intermediate and odd head counts are built to order. Each head has its own vaccine feed and its own counter.
How is the dose set?
Positive-displacement mechanical dosing, from 0.01 to 0.25 ml, set to the customer's protocol before the order; the setting can be changed on request.
Can the machine run different vaccines at the same time?
Yes. Each head has its own vaccine feed and its own stroke setting, so on the AEV-8 each of the eight heads can carry a different formulation, and a change of formulation does not call for recalibration.
Can it be used at sea cage sites?
Yes. It runs in land-based hatcheries and on floating platforms at sea cage sites.
What does installation require?
Compressed air and electricity only. Installation on site, operator training and remote support through the season are provided.
Where is the machine made?
In Urla, İzmir, Türkiye. It is CE marked and has been running in daily commercial production since 2025.
What does an automatic fish vaccinator do differently from hand vaccination?
It vaccinates every fish at the same point and to the same depth; the dose is mechanically fixed; the operator's hands stay clear of the needle while the machine is running; and each head keeps its own count.
Company information
The company behind the brand
Aegean Vaccine is the automated fish vaccination machine brand of İzmir Paketleme Lojistik İnşaat Sanayi ve Ticaret Ltd. Şti. The company supplies vaccines and immunostimulant feed additives, builds vaccination programmes by species and pathogen, and carries them out on site. That experience spans every generation of vaccine the sector has used, from early inactivated bacterins to today's oil-adjuvanted multivalent formulations, and from immersion and oral delivery to intraperitoneal injection. The legal entity you would be contracting with is set out below.
- Legal entityİzmir Paketleme Lojistik İnşaat Sanayi ve Ticaret Ltd. Şti.
- BrandAegean Vaccine
- LocationUrla, İzmir, Türkiye
- Websiteaegeanvaccine.com
- LinkedInlinkedin.com/company/aegean-vaccine
Start a conversation
Kenan Ateş
Founder and Managing Director
Aegean Vaccine
İzmir Paketleme Lojistik İnşaat Sanayi ve Ticaret Ltd. Şti.
Urla, İzmir, Türkiye
Founder
Kenan Ateş
LinkedIn profileHe entered the sector in 1988 at Mordoğan Su Ürünleri, which was then the second hatchery in Türkiye, and went on to build hatchery and pre-growing units from the ground up. He was part of the team behind some of the first fish vaccination work carried out in Türkiye. From 2002 to 2010, at Teknofarm, he managed the Aegean field application and logistics for the fish vaccines of Alpharma, then one of the largest developers of fish vaccines in the Mediterranean basin. He founded his own fish health company in 2010 and began developing the fish vaccination machine in 2022.
- 1988–1996Mordoğan Su Ürünleri — facility built from the ground up; broodstock and larval rearing management
- 1996–2000Kılıç Deniz Ürünleri Üretimi İhracat İthalat ve Ticaret A.Ş. — hatchery built in Milas Ören; broodstock and adaptation management
- 2000–2002Pınar Deniz Ürünleri — pre-growing and vaccination unit built and run
- 2002–2010Teknofarm — Aegean field application and logistics management for Alpharma fish vaccines
- 2010Own fish health and vaccine company founded
- 2022Development of the automated fish vaccination machine begins
- 2025The machine enters daily commercial production
